MTU brush seals can be used under the most varied of operating conditions and fully meet the stringent requirements imposed on advanced sealing systems. MTU brush seals can be used for static and dynamic applications alike. They are suitable for operation in a variety of fluids and are capable of withstanding high operating loads.
Operating conditions
| Application: | static / dynamic |
| Operating media: | gas / fluids |
| Max. differential pressure per sealing element: | up to 2,000 kPa |
| Max. differential pressure of several sealing elements installed one behind the other: | up to 6,500 kPa |
| Temperature: | up to 700 degrees Celsius |
| Sliding speed: | up to 500 m/s |
| Relative radial movement: | up to 4 mm |
| Relative axial movement: | unlimited |
